Product Details:
|
| Product Name: | Military Bomb Jammer | Range: | Up To 500m |
|---|---|---|---|
| Jamming Frequency: | 2G 3G 4G 5G GPS WiFi | Operating Humidity: | 5% - 95% |
| Packing Size: | 800 X 700 X 600mm | Weight: | 60kgs |
| High Light: | 400w Mobile Phone Signal Jammer,8 Antennas Mobile Phone Signal Jammer,500m Range Luggage Bomb Jammer |
||
400w Mobile Phone Signal Jammer 8 Antennas 2G 3G 4G 5G GPS 500m Range Military Used
Descriptions:
IED Jammer SA-008M can neutralize / prevent deadly criminal acts such as radio controlled Car Bombs, roadside bombs, ambush by remote IED attacks, assassinations, and remote controlled terrorist events. In addition to implementing High Power IED Jammers and Convoy Jammers, we have also designed and deployed facility jammers with dual functionality.
One of the 400W Portable Mobile Phone 8 Bands with Pelican case 1620 Jammer, up to 500m,Omni or Directional Antennas used. High power mobile phone jammer which are currently presented on the market. The luggage high power jammer includes battery, it can work about 2 hours. This backpack jammer can block 2g 3g 4g 5g wifi gps uhf vhf and etc signals. It is well used in military.
Specification:
Total Outputpower:300W (50walt/per band)
Cover Radius: 300-1000m(under Signal level ≤-85dBm)@according to the signal density mobile network)
Antenna type: High gain 5-7 dbi Omni-directional antennas
Power Supply: AC adapter 50 to 60Hz,AC110-240V to DC27V
Build-in rechargeable Battery 27V 20Ah
Cooling System:High efficiency aluminum alloy radiator+ 30 x cooling fans
Working Time:working 1.5hours by battery
Working temperature: -30~60℃
Dimension(LXWXH): 800 x 700x 350mm not include antennas
Package Size:550x450x300mm
Weight:56kg (6kg antennas)
| No. | Function | Remarks |
| 1 | RF Module |
A: Module Handle- - Take Out Each Module B: Power Adjust Switch- -Adjust Each Band Output Power Max To Off C: PILOT LIGHT: P: Working Power Light VSWR: Antenna Connect Wrong Alarm H: Output Power ≥30Watt M: Output Power ≥15Watt L: Output Power ≥5Watt D: Channel Number--Fit To Antennas Number E: Type M Connector- -Connect With Cable And Antennas F: Built-In Cooling Fans--The Wind Blows Out G: DC24-28V IN Plug |
| 2 | Colling System | Build-In 8 Pcs High Speed Cooling Fans, The Wind Blows In |
| 3 | Device Handle | Take Out The Internal Structure Of Device |
| 4 | Power Switch |
The Device AC DC Power Switch Forbid Opening At The Same Time |
| 5 | Power Supply Port |
AC220V Input Jack External Battery DC24-28V Input Jack Forbid Input At The Same Time |
| 6 | Extendable Module | Extend One More Module To Eight Bands |
| 7 | Draw Bar | Pull The Device To The Outside |
| Channel | Frequency | RF Power |
| CH1 | 850-894MHz | 50W |
| CH2 | 925-960MHz | 5W |
| CH3 | 1805-1990MHz | 50W |
| CH4 | 2110-2170MHz | 50W |
| CH5 | 2345-2400Mhz 2620-2690MHz | 50W |
| CH6 | 725-760MHz Or 790-826MHz | 50W |
| CH7 | 1570-1580MHz | 50W |
| CH8 | 2400-2500MHz | 50W |
Other Parameters
| Total Weight | 60kg |
| Ambient Temperature | -10℃~+50℃ |
| Relative Humidity | ≤80% |
| Power Consumption | ≤360W |
| Power Input | AC100~240V,DC24V |
| Battery | 24V,33AH,Built-In Standby Battery Can Used For 90~120 Minutes |
| Antenna Parameters | Omni Antennas,Gain:4~5dBi |
| Switch Control | Manually |
| Equipment Chassis | Metallic Paint |
Applicable Place:
Anti-Terror Units, Bomb Squads, VIP Protection, Convoys Protection, Military Forces, SWAT Teams, Police Forces, Anti-Drug Units, Riot-Control Units, Embassies Protection, Roadblock Protection, Checkpoint Protection.
Package Contents:
1pc Backpack Jammer
1pc AC 110 Or 220V DC 24V Or 27V 20A Power Supplier
8pcs Antennas Omni 500mm Long
