Product Details:
|
| Product Name: | Desktop Signal Blocker | Output Power: | 80w |
|---|---|---|---|
| Jamming Frequencies: | 2G 3G 4G 5G WiFi GPS | Power Supply: | AC110-240V To DC24V |
| Weight: | 8kgs | Dimension: | 52x45x15(cm) |
| High Light: | 5.8G Bluetooth WiFi Signal Jammer,80w WiFi Signal Jammer,DCS PCS Signal Jamming Device |
||
12 Antennas DC24V 80w Power Indoor 2.4G 5.8G Bluetooth WiFi Signal Jammer Factory
Description:
This new powerful cellphone WIFI GPS 5G signal jammer SA-012N is designed with 12 antennas which bring us a strong jamming ability. And it can not only cut off all 3G 4G 5G mobile phone signals, but also block WiFi GPS LOJACK signals. And with Adjustable 80 watts high power, the jamming radius of this device can be up to 80 meters at most depending on the signal strength in the detailed place.Built-in 9 Cooling Fans non-stop working. This jamming device is famous in Middle East and Africa, South America. It is indoor desktop wireless signal blocker, it works 24 hours non-stopped. Usually installed in prisons and meeting rooms.
Advantage:
12 chancel design, 3-10watts each band
High output power, Total up to: 90W, jamming up to 80m (Still depends on the strength signal in given area)
External high gain 2-3dbi Omni-directional antennas all the TX frequency covered down link only
Built-in good cooling system inside 9 fans, Working non-stopped
LED pilot light of each band. Can adjust power or turn off any single band without influencing the other bands operation
Independent module design with frequency source of each channel, easy maintenance (if have any damaged frequency band, replace with new PCB directly, no need for professional equipment such as frequency analyzer)
ODM and OEM orders are welcome, you can select any 12 bands for your require.
Notice: If you want to use this device in car, pls buy an inverter of DC12V/24V to AC110-240V, Power≥500Watts
Specifications:
| Specifications: SA-012N-5G | |||
| Channel | Output port | Frequency range | Average out-putting power |
| 1 | CDMA850 | 851-894MHz | 40dBm/10W |
| 2 | GSM900 | 925-960MHz | 40dBm/10W |
| 3 | DCS/PCS | 1805-1880 or 1920-2000MHz | 39dBm/8W |
| 4 | 3G2100 | 2110-2170MHz | 39dBm/8W |
| 5 | 4GLTE Low | 698-803 or 738-821MHz | 40dBm/10W |
| 6 | 4GLTE High | 2496-2690 or 2570-2690MHz | 38dBm/6W |
| 7 | 5G600/5G1500 | 617-685 or 1427-1518MHz | 38dBm/6W |
| 8 | 5G3500 | 3400-3600MHz | 35dBm/3W |
| 9 | 5G3700 | 3600-3800MHz | 35dBm/3W |
| 10 | WIFI2.4G/Bluetooth | 2400-2500MHz | 39dBm/8W |
| 11 | WIFI5.2G | 5100-5500MHz | 35dBm/3W |
| 12 | WIFI5.8G | 5500-5900MHz | 35dBm/3W |
| Power supply: Build-in AC adapter 50 to 60Hz, (AC110-240V IN, DC24V working) | |||
| Dimensions: (length ,width, height) 320x 310x 91mm(not Include Antenna) | |||
| Packing size: 52x45x15cm Net weight: 7.0kg Gross weight: 8.0kg | |||
| Total power:80W Shielding radius: (10-80) meters At -75dBm Still depends on the strength signal in given area, Shielding radius of VHF/UHF signal about 30meters |
|||
| Warranty: one year from delivery date | |||
OEM Customized Service
Silkscreen OEM service can be offered.
