Product Details:
|
| Product Name: | Anti Gun Uav Drone Jammer Blocker | Output Power: | 200w |
|---|---|---|---|
| Power Supply: | AC/DC Adapter | Jamming Range: | 2000-2500(m) |
| Operating Temperature: | -40ºC To +65ºC | Antenna: | 8pcs Directional Antenna |
| Battery Working Time: | 40-50min | Dimensions: | 820*300*80mm |
| High Light: | long distance anti drone signal jammer,200w anti drone signal jammer,8 Bands anti drone signal blocker |
||
Introducing the Drone Signal Jammer, the ultimate gun type blocker specifically designed to protect your airspace from drones. This powerful 200W device is capable of jamming and blocking most of the drone signals on the market, giving you the power to take back control. With its high-performance, 6.45kg weight, and -40ºC to +65ºC operating temperature, the Drone Signal Jammer is the perfect solution for securing your airspace from unwanted drones. Whether you need a drone jammer blocker, drone signal blocker, or drone signal blocker gun, this device has you covered.
1. Please check the LCD screen to ensure the jammer is fully charged
2. Choose the frequency band to jam, and press the button
3. Target the drone gun at the flying drone in sky
4. Drone will be forced to return home or land immediately
Pressing the choosen buttons as below sheet to act its jamming function
| Usually below channels pressed, the jammer can counter |
| > 95% jammer in the market. |
| Channel: 2.4 Ghz |
| Channel: 5.8 GHz |
| Channel: 1.5 GHz |
Technical Specification
| Model No. | SA-UAV-SJ084 |
| Size | 820*300*80mm |
| Weight | 6.45kg |
| Effective Range | 2000-2500 meter,depends on real environment |
| Frequency & Output Power |
410-485 MHz ( 433 MHz) 10W |
| 840-920 MHz ( 900MHz) 10W | |
| 1100-1280 MHz (1.2 GHz) 10W | |
| 1300-1390 MHz (1.4 GHz) 10W | |
| 1560-1620 MHz (1.5 GHz) 30W | |
| 2400-2500 MHz (2.4 GHz) 50W | |
| 5150-5350 MHz (5.2 GHz) 30W | |
| 5725-5850 MHz ( 5.8 GHz) 50W | |
| Total 200W | |
| Inside Antenna Gain | 433Mhz /5dBi |
| 2400MHz /14dBi | |
| 2400MHz /14dBi | |
| GPSL1-L5(1.2G/11dBi,11.5G/12dBi) | |
| 5800MHz /16dBi | |
| 5200MHz /16dBi | |
| 900MHz. /9dBi | |
| Output Power | Total 200 Watt |
| Battery Use Time | 40-50 minute |
| Working temperature | -40ºC to +65ºC |
| Power Supply | 24V 10A inside lithium-ion battery |
| (It can be designed to connect the external battery) | |
| Relative Humidity | 35~85% |
Applications:
To avoid the rapidly emerging threat by UAV, our jammer can be used in below recommend places:
1. Government: Prison, Court, Military, Police, other Law enforcement, etc
2. Infrastructure: Petrol Station, Oil Depot, Gas Station, Airport, Drug rehabilitation centers, Security agency, etc
3. Public&Events: Stadium&Events, Important Meetings,etc
4. Transportation: Port&marine, Superyachts, etc
5. Detention Centers, School (examination,library,etc),Theatre,Church, Hospital,etc
6. Personal VIP&Privacy,etc
1. All band open at same time will consume large power; please use it less than 5 minute to lengthen the battery life time;
2. Please fully charge the jammer before use;
3. Please ensure the jamming frequency is suitable for your own need, or it can not be used effectively;
4. Forbidden to use while charging;
5. Barriers between the UAV and jammer will influence the jamming distance
Full Set Packing
1pcs*Drone Jammer
1pcs*Battery
1pcs * Charger
* User manual be offered online
