8 Bands 200w high power long distance gun anti drone signal jammer blocker

8 Bands 200w high power long distance gun anti drone signal jammer blocker
8 Bands 200w high power long distance gun anti drone signal jammer blocker 8 Bands 200w high power long distance gun anti drone signal jammer blocker 8 Bands 200w high power long distance gun anti drone signal jammer blocker 8 Bands 200w high power long distance gun anti drone signal jammer blocker

Large Image :  8 Bands 200w high power long distance gun anti drone signal jammer blocker

Product Details:
Place of Origin: China
Brand Name: Sacontelecom
Certification: ISO9001
Model Number: SA-UAV-SJ084
Payment & Shipping Terms:
Minimum Order Quantity: 3pcs
Price: negotiation
Packaging Details: alum case
Delivery Time: within 3 days after payment
Payment Terms: TT by Bank, Western Union
Supply Ability: 5000pcs/month

8 Bands 200w high power long distance gun anti drone signal jammer blocker

Description
Product Name: Anti Gun Uav Drone Jammer Blocker Output Power: 200w
Power Supply: AC/DC Adapter Jamming Range: 2000-2500(m)
Operating Temperature: -40ºC To +65ºC Antenna: 8pcs Directional Antenna
Battery Working Time: 40-50min Dimensions: 820*300*80mm

8 Bands 200w high power long distance gun anti drone signal jammer blocker

Product Description:

Introducing the Drone Signal Jammer, the ultimate gun type blocker specifically designed to protect your airspace from drones. This powerful 200W device is capable of jamming and blocking most of the drone signals on the market, giving you the power to take back control. With its high-performance, 6.45kg weight, and -40ºC to +65ºC operating temperature, the Drone Signal Jammer is the perfect solution for securing your airspace from unwanted drones. Whether you need a drone jammer blocker, drone signal blocker, or drone signal blocker gun, this device has you covered.



Features:

  • Product Name: Drone Signal Jammer
  • Jamming Range: 2000-2500(m)
  • Type: Gun Type
  • Relative Humidity: 35~85%
  • Battery working time: 40-50min
  • Operating Temperature: -40ºC To +65ºC
  • Drone Jammer Blocker
  • Drone Gun Signal Jammer





How to Use:



1. Please check the LCD screen to ensure the jammer is fully charged

2. Choose the frequency band to jam, and press the button

3. Target the drone gun at the flying drone in sky

4. Drone will be forced to return home or land immediately



Pressing the choosen buttons as below sheet to act its jamming function



Usually below channels pressed, the jammer can counter
> 95% jammer in the market.
Channel: 2.4 Ghz
Channel: 5.8 GHz
Channel: 1.5 GHz







Technical Specification



Model No. SA-UAV-SJ084
Size 820*300*80mm
Weight 6.45kg
Effective Range 2000-2500 meter,depends on real environment

Frequency
&
Output Power
410-485 MHz ( 433 MHz) 10W
840-920 MHz ( 900MHz) 10W
1100-1280 MHz (1.2 GHz) 10W
1300-1390 MHz (1.4 GHz) 10W
1560-1620 MHz (1.5 GHz) 30W
2400-2500 MHz (2.4 GHz) 50W
5150-5350 MHz (5.2 GHz) 30W
5725-5850 MHz ( 5.8 GHz) 50W
Total 200W

Inside Antenna Gain 433Mhz /5dBi
2400MHz /14dBi
2400MHz /14dBi
GPSL1-L5(1.2G/11dBi,11.5G/12dBi)
5800MHz /16dBi
5200MHz /16dBi
900MHz. /9dBi

Output Power Total 200 Watt
Battery Use Time 40-50 minute
Working temperature -40ºC to +65ºC
Power Supply 24V 10A inside lithium-ion battery
(It can be designed to connect the external battery)
Relative Humidity 35~85%





Applications:



To avoid the rapidly emerging threat by UAV, our jammer can be used in below recommend places:



1. Government: Prison, Court, Military, Police, other Law enforcement, etc

2. Infrastructure: Petrol Station, Oil Depot, Gas Station, Airport, Drug rehabilitation centers, Security agency, etc

3. Public&Events: Stadium&Events, Important Meetings,etc

4. Transportation: Port&marine, Superyachts, etc

5. Detention Centers, School (examination,library,etc),Theatre,Church, Hospital,etc

6. Personal VIP&Privacy,etc



Caution

1. All band open at same time will consume large power; please use it less than 5 minute to lengthen the battery life time;

2. Please fully charge the jammer before use;

3. Please ensure the jamming frequency is suitable for your own need, or it can not be used effectively;

4. Forbidden to use while charging;

5. Barriers between the UAV and jammer will influence the jamming distance





Full Set Packing



1pcs*Drone Jammer

1pcs*Battery

1pcs * Charger

* User manual be offered online
