2.4G 5.8G Network Signal Drone Jamming Device UAV Drones Frequency 40w Handheld
Product Overview
The latest handheld middle power drone signal jammer SA-DJ04 provides comprehensive coverage for 100% of drones and UAVs, including DJI Phantom 4, Phantom 3 Professional, Advanced, Standard series, and Inspire Series. This device effectively jams UAV signals during flight operations, cutting off communication between the UAV and its controller, enabling controlled landing or return to designated safe locations.
Download Product Documentation
Key Features
- Simultaneously jams up to 4 frequency bands
- Separate frequency bands with adjustable power control (max to off)
- LED indicator lights display power supply status
- 100% safe VSWR over protection for each module
- Built-in battery with 60-90 minutes operating time
- Battery power and charger status displayed via LED screen
- Long jamming range up to 1200 meters
Applications
- Prisons and correctional centers
- Government compounds and sensitive locations
- Homeland Security operations
- Petrochemical industry facilities
- Sports venues and theaters
- VIP convoy protection
- Bomb prevention and disposal operations
- Schools and universities
- Power generating plants
Technical Specifications
| Output Interface |
Description |
Shield Band Frequency |
RF Output Power (±1w) |
| CH1 |
RC2.4G |
2400-2500MHz |
10w |
| CH2 |
RC5.8G |
5725-5850MHz |
10w |
| CH3 |
GPS L1 and Glonass L1 |
1560-1620MHz |
10w |
| CH4 |
GPS L2+L5 |
1170-1280MHz |
10w |
Power Supply: AC adapter 50 to 60Hz, AC110-240V to DC27V
Total Output Power: 40w
Power Consumption: 160w
Directional Jamming Range: 1000-1200 Meters (GPS signal for 1200m, under Signal level ≤-85dBm)
Antenna Type: Built-in High gain 5-7 dbi Panel directional antennas
Battery: +24V/5AH LiFe PO4
Working Time: 1.5 Hours
Dimensions (L×W×H): 380×260×95mm (not including antennas)
Inner Box Dimension: 450×350×300mm
Weight: 3.5kg
Frequently Asked Questions
Can I have a sample order?
Yes, we welcome sample orders to test and check quality. Mixed samples are acceptable.
What is the lead time?
Sample orders take 1-3 days, mass production time is 3-7 days for orders less than 100 pieces.
Do you have any MOQ limit?
Our MOQ EXW is 1 piece.
How do you ship the goods and how long does it take to arrive?
We usually ship by DHL, UPS, FedEx or TNT international express, taking 3-5 days to arrive. We can also ship by air or sea if needed.
Do you offer guarantee for the products?
Yes, we offer one year guarantee for the products.
Do you accept drop shipping?
Yes, drop shipping is available.
Package Contents
- 1 piece Drone Jammer
- 1 piece AC Charger
- 1 piece Carry Case
